The script will convert your drawing into a slideshow presentation.
```javascript
*/
if(!ea.verifyMinimumPluginVersion || !ea.verifyMinimumPluginVersion("1.8.17")) {
new Notice("This script requires a newer version of Excalidraw. Please install the latest version.");
return;
}
//constants
const STEPCOUNT = 100;
const FRAME_SLEEP = 1; //milliseconds
const EDIT_ZOOMOUT = 0.7; //70% of original slide zoom, set to a value between 1 and 0
//utility & convenience functions
const inPopoutWindow = ea.targetView.ownerDocument !== document;
const win = ea.targetView.ownerWindow;
const api = ea.getExcalidrawAPI();
const contentEl = ea.targetView.contentEl;
const sleep = async (ms) => new Promise((resolve) => setTimeout(resolve, ms));
//clean up potential clutter from previous run
window.removePresentationEventHandlers?.();
//check if line or arrow is selected, if not inform the user and terminate presentation
let lineEl = ea.getViewElements().filter(el=>["line","arrow"].contains(el.type) && el.customData?.slideshow)[0];
const selectedEl = ea.getViewSelectedElement();
let preventHideAction = false;
if(lineEl && selectedEl && ["line","arrow"].contains(selectedEl.type)) {
api.setToast({
message:"Using selected line instead of hidden line. Note that there is a hidden presentation path for this drawing. Run the slideshow script without selecting any elements to access the hidden presentation path",
duration: 5000,
closable: true
})
preventHideAction = true;
lineEl = selectedEl;
}
if(!lineEl) lineEl = selectedEl;
if(!lineEl || !["line","arrow"].contains(lineEl.type)) {
api.setToast({
message:"Please select the line or arrow for the presentation path",
duration: 3000,
closable: true
})
return;
}
//goto fullscreen
const gotoFullscreen = async () => {
if(app.isMobile) {
ea.viewToggleFullScreen(true);
} else {
if(!inPopoutWindow) {
await contentEl.webkitRequestFullscreen();
await sleep(500);
}
ea.setViewModeEnabled(true);
}
const deltaWidth = () => contentEl.clientWidth-api.getAppState().width;
let watchdog = 0;
while (deltaWidth()>50 && watchdog++<20) await sleep(100); //wait for Excalidraw to resize to fullscreen
contentEl.querySelector(".layer-ui__wrapper").addClass("excalidraw-hidden");
}
//hide the arrow and save the arrow color before doing so
const originalProps = lineEl.customData?.slideshow?.hidden
? lineEl.customData.slideshow.originalProps
: {
strokeColor: lineEl.strokeColor,
backgroundColor: lineEl.backgroundColor,
locked: lineEl.locked,
};
let hidden = lineEl.customData?.slideshow?.hidden ?? false;
const hideArrow = async (setToHidden) => {
ea.clear();
ea.copyViewElementsToEAforEditing(ea.getViewElements().filter(el=>el.id === lineEl.id));
const el = ea.getElement(lineEl.id);
el.strokeColor = "transparent";
el.backgroundColor = "transparent";
const customData = el.customData;
if(setToHidden && !preventHideAction) {
el.locked = true;
el.customData = {
...customData,
slideshow: {
originalProps,
hidden: true
}
}
hidden = true;
} else {
if(customData) delete el.customData.slideshow;
hidden = false;
}
await ea.addElementsToView();
}
//----------------------------
//scroll-to-location functions
//----------------------------
let slide = -1;
const slideCount = Math.floor(lineEl.points.length/2)-1;
const getNextSlide = (forward) => {
slide = forward
? slide < slideCount ? slide + 1 : 0
: slide <= 0 ? slideCount : slide - 1;
return {
pointA:lineEl.points[slide*2],
pointB:lineEl.points[slide*2+1]
}
}
const getSlideRect = ({pointA, pointB}) => {
const {width, height} = api.getAppState();
const x1 = lineEl.x+pointA[0];
const y1 = lineEl.y+pointA[1];
const x2 = lineEl.x+pointB[0];
const y2 = lineEl.y+pointB[1];
const ratioX = width/Math.abs(x1-x2);
const ratioY = height/Math.abs(y1-y2);
let ratio = ratioX<ratioY?ratioX:ratioY;
if (ratio < 0.1) ratio = 0.1;
if (ratio > 10) ratio = 10;
const deltaX = (ratio===ratioY)?(width/ratio - Math.abs(x1-x2))/2:0;
const deltaY = (ratio===ratioX)?(height/ratio - Math.abs(y1-y2))/2:0;
return {
left: (x1<x2?x1:x2)-deltaX,
top: (y1<y2?y1:y2)-deltaY,
right: (x1<x2?x2:x1)+deltaX,
bottom: (y1<y2?y2:y1)+deltaY,
nextZoom: ratio
};
}
let busy = false;
const scrollToNextRect = async ({left,top,right,bottom,nextZoom},steps = STEPCOUNT) => {
let watchdog = 0;
while(busy && watchdog++<15) await(100);
if(busy && watchdog >= 15) return;
busy = true;
api.updateScene({appState:{shouldCacheIgnoreZoom:true}});
const {scrollX, scrollY, zoom} = api.getAppState();
const zoomStep = (zoom.value-nextZoom)/steps;
const xStep = (left+scrollX)/steps;
const yStep = (top+scrollY)/steps;
for(i=1;i<=steps;i++) {
api.updateScene({
appState: {
scrollX:scrollX-(xStep*i),
scrollY:scrollY-(yStep*i),
zoom:{value:zoom.value-zoomStep*i},
}
});
await sleep(FRAME_SLEEP);
}
api.updateScene({appState:{shouldCacheIgnoreZoom:false}});
busy = false;
}
const navigate = async (dir) => {
const forward = dir === "fwd";
const prevSlide = slide;
const nextSlide = getNextSlide(forward);
//exit if user navigates from last slide forward or first slide backward
const shouldExit = forward
? slide<=prevSlide
: slide>=prevSlide;
if(shouldExit) {
exitPresentation();
return;
}
if(slideNumberEl) slideNumberEl.innerText = `${slide+1}/${slideCount+1}`;
const nextRect = getSlideRect(nextSlide);
await scrollToNextRect(nextRect);
if(settingsModal) {
slideNumberDropdown.setValue(`${slide}`.padStart(3,"0"));
}
}
//--------------------------
// Settings Modal
//--------------------------
let settingsModal;
let slideNumberDropdown;
const presentationSettings = () => {
let dirty = false;
settingsModal = new ea.obsidian.Modal(app);
const getSlideNumberLabel = (i) => {
switch(i) {
case 0: return "1 - Start";
case slideCount: return `${i+1} - End`;
default: return `${i+1}`;
}
}
const getSlidesList = () => {
const options = {};
for(i=0;i<=slideCount;i++) {
options[`${i}`.padStart(3,"0")] = getSlideNumberLabel(i);
}
return options;
}
settingsModal.onOpen = () => {
settingsModal.contentEl.createEl("h1",{text: "Slideshow Actions"});
settingsModal.contentEl.createEl("p",{text: "To open this window double click presentation script icon or press ENTER during presentation."});
new ea.obsidian.Setting(settingsModal.contentEl)
.setName("Jump to slide")
.addDropdown(dropdown => {
slideNumberDropdown = dropdown;
dropdown
.addOptions(getSlidesList())
.setValue(`${slide}`.padStart(3,"0"))
.onChange(value => {
slide = parseInt(value)-1;
navigate("fwd");
})
})
if(!preventHideAction) {
new ea.obsidian.Setting(settingsModal.contentEl)
.setName("Hide navigation arrow after slideshow")
.setDesc("Toggle on: arrow hidden, toggle off: arrow visible")
.addToggle(toggle => toggle
.setValue(hidden)
.onChange(value => hideArrow(value))
)
}
new ea.obsidian.Setting(settingsModal.contentEl)
.setName("Edit current slide")
.setDesc("Pressing 'e' during the presentation will open the current slide for editing.")
.addButton(button => button
.setButtonText("Edit")
.onClick(async ()=>{
await hideArrow(false);
exitPresentation(true);
})
)
}
settingsModal.onClose = () => {
setTimeout(()=>delete settingsModal);
}
settingsModal.open();
contentEl.appendChild(settingsModal.containerEl);
}
//--------------------------------------
//Slideshow control
//--------------------------------------
let controlPanelEl;
let slideNumberEl;
const createNavigationPanel = () => {
//create slideshow controlpanel container
const top = contentEl.innerHeight;
const left = contentEl.innerWidth;
controlPanelEl = contentEl.createDiv({
cls: ["excalidraw","excalidraw-presentation-panel"],
attr: {
style: `
width: calc(var(--default-button-size)*3);
z-index:5;
position: absolute;
top:calc(${top}px - var(--default-button-size)*2);
left:calc(${left}px - var(--default-button-size)*3.5);`
}
});
const panelColumn = controlPanelEl.createDiv({
cls: "panelColumn",
});
panelColumn.createDiv({
cls: ["Island", "buttonList"],
attr: {
style: `
height: calc(var(--default-button-size)*1.5);
width: 100%;
background: var(--island-bg-color);`,
}
}, el=>{
el.createEl("button",{
text: "<",
attr: {
style: `
margin-top: calc(var(--default-button-size)*0.25);
margin-left: calc(var(--default-button-size)*0.25);`
}
}, button => button .onclick = () => navigate("bkwd"));
el.createEl("button",{
text: ">",
attr: {
style: `
margin-top: calc(var(--default-button-size)*0.25);
margin-right: calc(var(--default-button-size)*0.25);`
}
}, button => button.onclick = () => navigate("fwd"));
slideNumberEl = el.createEl("span",{
text: "1",
cls: ["ToolIcon__keybinding"],
})
});
}
//keyboard navigation
const keydownListener = (e) => {
e.preventDefault();
switch(e.key) {
case "Escape":
if(app.isMobile || inPopoutWindow) exitPresentation();
break;
case "ArrowRight":
case "ArrowDown":
navigate("fwd");
break;
case "ArrowLeft":
case "ArrowUp":
navigate("bkwd");
break;
case "Enter":
presentationSettings();
break;
case "End":
slide = slideCount - 1;
navigate("fwd");
break;
case "Home":
slide = -1;
navigate("fwd");
break;
case "e":
(async ()=>{
await hideArrow(false);
exitPresentation(true);
})()
break;
}
}
//slideshow panel drag
let pos1 = pos2 = pos3 = pos4 = 0;
const updatePosition = (deltaY = 0, deltaX = 0) => {
const {
offsetTop,
offsetLeft,
clientWidth: width,
clientHeight: height,
} = controlPanelEl;
controlPanelEl.style.top = (offsetTop - deltaY) + 'px';
controlPanelEl.style.left = (offsetLeft - deltaX) + 'px';
}
const pointerUp = () => {
win.removeEventListener('pointermove', onDrag, true);
}
let dblClickTimer = 0;
const pointerDown = (e) => {
const now = Date.now();
pos3 = e.clientX;
pos4 = e.clientY;
win.addEventListener('pointermove', onDrag, true);
if(now-dblClickTimer < 400) {
presentationSettings();
}
dblClickTimer = now;
}
const onDrag = (e) => {
e.preventDefault();
pos1 = pos3 - e.clientX;
pos2 = pos4 - e.clientY;
pos3 = e.clientX;
pos4 = e.clientY;
updatePosition(pos2, pos1);
}
const initializeEventListners = () => {
win.addEventListener('keydown',keydownListener);
controlPanelEl.addEventListener('pointerdown', pointerDown, false);
win.addEventListener('pointerup', pointerUp, false);
//event listners for terminating the presentation
window.removePresentationEventHandlers = () => {
ea.onLinkClickHook = null;
controlPanelEl.parentElement?.removeChild(controlPanelEl);
if(!app.isMobile) win.removeEventListener('fullscreenchange', fullscreenListener);
win.removeEventListener('keydown',keydownListener);
win.removeEventListener('pointerup',pointerUp);
contentEl.querySelector(".layer-ui__wrapper")?.removeClass("excalidraw-hidden");
delete window.removePresentationEventHandlers;
}
ea.onLinkClickHook = () => {
exitPresentation();
return true;
};
if(!app.isMobile) {
win.addEventListener('fullscreenchange', fullscreenListener);
}
}
const exitPresentation = async (openForEdit = false) => {
if(openForEdit) ea.targetView.preventAutozoom();
if(!app.isMobile && !inPopoutWindow && document?.fullscreenElement) await document.exitFullscreen();
if(app.isMobile) {
ea.viewToggleFullScreen(true);
} else {
ea.setViewModeEnabled(false);
}
if(settingsModal) settingsModal.close();
ea.clear();
ea.copyViewElementsToEAforEditing(ea.getViewElements().filter(el=>el.id === lineEl.id));
const el = ea.getElement(lineEl.id);
if(!hidden) {
el.strokeColor = originalProps.strokeColor;
el.backgroundProps = originalProps.backgroundColor;
el.locked = openForEdit ? false : originalProps.locked;
}
await ea.addElementsToView();
if(!hidden) ea.selectElementsInView([el]);
if(openForEdit) {
const nextSlide = getNextSlide(--slide);
let nextRect = getSlideRect(nextSlide);
const offsetW = (nextRect.right-nextRect.left)*(1-EDIT_ZOOMOUT)/2;
const offsetH = (nextRect.bottom-nextRect.top)*(1-EDIT_ZOOMOUT)/2
nextRect = {
left: nextRect.left-offsetW,
right: nextRect.right+offsetW,
top: nextRect.top-offsetH,
bottom: nextRect.bottom+offsetH,
nextZoom: nextRect.nextZoom*EDIT_ZOOMOUT > 0.1 ? nextRect.nextZoom*EDIT_ZOOMOUT : 0.1 //0.1 is the minimu zoom value
};
await scrollToNextRect(nextRect,1);
api.startLineEditor(
ea.getViewSelectedElement(),
[slide*2,slide*2+1]
);
}
window.removePresentationEventHandlers?.();
setTimeout(()=>{
//Resets pointer offsets. Ugly solution.
//During testing offsets were wrong after presentation, but don't know why.
//This should solve it even if they are wrong.
ea.targetView.refresh();
})
}
const fullscreenListener = (e) => {
e.preventDefault();
exitPresentation();
}
//--------------------------
// Start presentation or open presentation settings on double click
//--------------------------
const start = async () => {
await gotoFullscreen();
await hideArrow(hidden);
createNavigationPanel();
initializeEventListners();
//navigate to the first slide on start
setTimeout(()=>navigate("fwd"));
}
const timestamp = Date.now();
if(window.ExcalidrawSlideshow && (window.ExcalidrawSlideshow.script === utils.scriptFile.path) && (timestamp - window.ExcalidrawSlideshow.timestamp <400) ) {
if(window.ExcalidrawSlideshowStartTimer) {
clearTimeout(window.ExcalidrawSlideshowStartTimer);
delete window.ExcalidrawSlideshowStartTimer;
}
await start();
presentationSettings();
} else {
window.ExcalidrawSlideshow = {
script: utils.scriptFile.path,
timestamp
};
window.ExcalidrawSlideshowStartTimer = setTimeout(start,500);
}
